8x CoaXPress-6 Frame grabber & Image Processing System
- Up to 50 Gb/s bandwidth via 8x CoaXPress-6 links
- Ideal for Recording & Streaming solutions
- Inline Image Processing option including:
- On-FPGA real-time Compression (.JPEG, Lossless, Quality+)
- Real-Time High Dynamic Range (HDR) correction
- Supports 100+ synchronized cameras using the InfiniVision
- Memory: up to 33 GB
- Form factor: full-height, single-slot, half-length PCI Express card
Proc10A-CXP: Octo CXP 6 Frame Grabber with Real-Time Image Processing
The Proc10A-CXP is a high-performance Octo CXP 6 Frame Grabber designed for real-time image acquisition, processing, and compression in demanding multi-camera vision environments. Powered by Altera Arria 10 FPGA technology, it supports up to 8× CXP-6 links, delivering simultaneous acquisition from up to 8 cameras with 33 GB on-board memory. As a result, it ensures zero frame loss, ultra-low latency, and negligible CPU load, making it ideal for mission-critical applications.
Performance and Real-Time Image Processing
The Proc10A-CXP is available as a plug-and-play CXP frame grabber or as part of a complete solution integrating image acquisition, modular real-time preprocessing, enhancement, and advanced compression IPs (JPEG, Lossless, Quality+).
Inline enhancement features include:
-
High Dynamic Range (HDR) – Captures superior details in high-contrast lighting conditions.
-
White Balance – Maintains color accuracy across variable lighting conditions.
-
Dynamic Luminance Balance – Preserves consistent brightness under changing illumination.
-
Gamma Correction – Optimizes brightness and contrast for improved clarity.
Real-time compression with Dynamic ROI delivers:
-
Extended recording times without compromising quality.
-
Lower transmission bandwidth for efficient data handling.
-
Accelerated offline compression, reducing storage needs and post-processing time.
InfiniVision Architecture – Multi-Camera CXP Frame Grabber
Gidel’s InfiniVision architecture addresses critical multi-camera challenges, including bandwidth, synchronization, connectivity, and scalability. Consequently, the Proc10A-CXP, Octo CXP frame grabber supports up to 8x CXP-6 links, enabling 1–8 cameras to operate seamlessly with consistent high-speed throughput.
Additionally, a PCIe Gen3 x8 interface ensures CPU-free, ultra-fast data transfer, while on-board 33 GB buffers enhance acquisition stability and enable real-time FPGA-based image processing. As a result, the Proc10A-CXP delivers reliable performance in high-resolution, high-speed imaging systems.
Flexible Operating Modes
The Proc10A-CXP supports two operating modes selectable via firmware:
-
InfiniVision: Ideal for synchronized multi-camera setups, combining all camera data—even across multiple cards—into a single buffer with support for dynamic resolutions and formats.
-
ProcFG: Optimized for line-scan cameras, offering fixed frame sizes, pixel formats, and ROI grabbing (uncompressed).
As a result, the Proc10A-CXP adapts to diverse workflows, from complex multi-camera systems to single-camera applications requiring consistent, high-performance acquisition.
SDK and Development Tools
The Proc10A-CXP is supported by Gidel’s SDK, featuring intuitive GUIs and APIs for easy integration. Moreover, the ProcVision Suite adds advanced FPGA programming, debugging, and validation tools, enabling rapid customization of data pipelines, real-time processing, and compression workflows. Consequently, developers can deploy optimized, application-specific solutions faster and with reduced risk.
Why Choose the Proc10A-CXP? (Octo CXP 6 Frame Grabber)
-
Supports up to 8× CXP-6 links for high-bandwidth acquisition.
-
FPGA-based real-time processing with HDR, white balance, and gamma correction.
-
Dynamic ROI compression for storage and bandwidth efficiency.
-
Flexible operating modes to suit multi-camera and line-scan setups.
-
Advanced SDK and ProcVision Suite for rapid development and integration.
Looking for an Octo CoaXPress-12 Frame Grabber solution? see Proc1C10N-CXP12.
Need a compact Quad CXP-12 Frame Grabber? refer to HawkEye-CXP12.
For a Jetson-based Quad CoaXPress-12 solution, visit FantoVision40-CXP12 Edge Computer Vision System.
For a Jetson with Quad CXP12 & 10GigE Vision Interfaces, see FantoVision40 Edge Computer Vision System.
General
Camera Input
- 8x CoaXPress-6 links
- 4x CoaXPress-6 links
- PoCXP
CoaXPress Version
CoaXPress 2.1
Camera Input Connectors
8x Micro-BNC
Additional Connectors
- JTAG
- VGA15-pin for connecting GPIO's to the bracket
- 16-pin board-to-board header
Supported down-connection speeds
- 1.25 Gb/s | CXP-1
- 2.5 Gb/s | CXP-2
- 3.125 Gb/s | CXP-3
- 5 Gb/s | CXP-5
- 6.25 Gb/s | CXP-6
Supported up-connection speeds
20.83 Mbps (CXP-1 to CXP-6)
Maximum Stream Packet Size
8,192 bytes
Advanced ROI feature
On-the -fly selective ROI acquisition
Image Formats
- Mono, Bayer, RGBA (8, 10, 12, 14 and 16 bits/color)
- RGB (8, 10 and 12 bits/color)
Max Resolution
- Horizontal: 16 K pixels (64-bit)
- Vertical: 65 K lines
Maximum Acquisition Throughput
40 Gb/s
Compression & Image Enhancements
Host Bus
PCIe x8 Gen. 3
On Board Memory
Up to 17 GB
Camera Types
- Area
- Line Scan
Form Factor
Single-slot, full-height half-length PCIe card
GPIO
External IO - 12x LVTTL
Cooling
Passive cooling | Active cooling (fan)
MTBF (with passive cooling)
> Million hours (With Passive Cooling)
Environmental conditions
Temperature
Operating ambient air temperature: 0 – 55° C
Humidity
- Continuous Operation: 10 - 80% (non-condensing)
- Peak Operation: 10 - 90% (non-condensing)
Environmental Compliance
The Proc10A-CXP Frame Grabber is a highly modular solution, designed to be tailored to meet unique application requirements.
Looking to adapt the Proc10A-CXP to match your vision?
The Proc10A-CXP frame grabber offers two powerful customization paths to meet specific application requirements:
-
Modular Pre-Configured Features
Gidel provides a range of pre-embedded modules tailored to your specifications—such as real-time compression, HDR, and other advanced features. (See the Options tab for available configurations.) -
User-Level FPGA Customization
Leverage Gidel’s development tools and IP libraries to integrate your proprietary FPGA logic and extend the system’s capabilities for acquisition, image processing, and control.
The Gidel ProcVision Suite delivers a complete toolchain for advanced user-level FPGA customization of the data flow, image pipeline, image processing, and more—ensuring optimal performance for your vision or imaging application.
Proc10A-CXP: FPGA resource comparison
| Model | Proc10A-CXP-027 | Proc10A-CXP-066 | Proc10A-CXP-115 |
|---|---|---|---|
| FPGA | Altera Arria 10 GX 270 | Altera Arria 10 GX 660 | Altera Arria 10 GX 1150 |
| FPGA-ALM | 101,620 | 250,540 | 427,200 |
| FPGA-M20K | 750 | 2,133 | 2,713 |
| FPGA - 18 x 19 Multiplier | 1,660 | 3,556 | 3,036 |
| Peripheral Memory: | |||
|
|
1 GB | 1 GB | 1 GB |
|
|
5.6 GB/s | 5.6 GB/s | 5.6 GB/s |
|
|
0, 8,16 GB | 0, 8,16 GB | 0, 8,16 GB |
|
|
8.96 GB/s | 8.96 GB/s | 8.96 GB/s |
|
|
0, 8,16 GB | 0, 8,16 GB | 0, 8,16 GB |
|
|
8.96 GB/s | 8.96 GB/s | 8.96 GB/s |
Grabbers SDK
InfiniVision
Designed for acquisition from a large number of cameras (100+), with an option for embedded real-time compression.
ProcFG
Optimized for line-scan camera acquisition, combining ROI-based grabbing with integrated debugging and analysis tools.
Application Interfaces
GUI Applications
- InfiniVision
- ProcFG
- CameraConfig – Camera discovery and configuration
- ggvcon – GigE Vision network configuration
APIs
- InfiniVision with supporting examples
- ProcFG with supporting examples
- Gen<i>Cam GenTL producer libraries compatible with C/C++ compilers
- InitCam for developing user Gen<i>Cam camera configuration application
- GigE for developing camera network communication applications
Software Compatibility
Third-party software
- MVTec Halcon machine vision software
- Camera control Gen<i>Cam based application
Operation Systems supported
- Windows 11
- Windows 10
- Windows Server 2022
- Windows Server 2019
- Windows Server 2016
- Linux (kernel 2.6.x- 6.12)
| Name | Description | Type | Size | |
|---|---|---|---|---|
|
Proc10A-CXP
|
Datasheet | 296.0 KB | ||
|
Proc10A-CXP
|
Block diagram | PNG | 396.9 KB |
